CPT030A
18W Wireless Power Transmitter Wide-Area Power Pad
Using Magnetic Resonance Wireless Power Transfer, this Wide-Area Power Pad brings full spatial freedom to wireless charging/powering with capability to provide multiple device charging and supporting arbitrary placement of receiving devices of different power levels.
• Output Power: support up to 18W delivery to load when paired with Power Receiver(s)
• Power area: 420 x 350mm
• Power Distance: 0mm optimum
• Dimention: 435 x 360 x7mm (pad); 200 x 86 x23mm (control box)
Products
Specifications
Electrical
Mechanical
Environmental
Electrical
| Electrical Specification | |||||
| PTU | |||||
| Characteristics | Condition | Min. | Typ. | Max. | Units |
| Input voltage | 46 | 48 | 50 | Voltage | |
| Rated input current | 2 | Amp | |||
| Resonator Output | 18 | Watt | |||
| Operating Frequency | 6.78 | Mhz | |||
| (Centered) | System DC-DC efficiency (PTU & PRU) | 50 | % | ||
| PRU efficiency | 85 | % | |||
| Over Power Protection | 60 | Watt | |||
| Over Temperature protection | 90 | °C |
Mechanical
| Mechanical Specification | |
| Dimension | 200 mm (l) x 86 mm (w) x 22 mm (h) (Control board) |
| 400 mm (l) x 350 mm x 7 mm (h) (Coil Board) | |
| Weight | |
| Coil type | Copper wire wound |
| Coil dimension | 400 mm (l) x 350 mm (w) |
Environmental
| Environmental Specification | |||||
| Operating Ambient Temperature | 0 | 35 | °C | ||
| Storage Temperature | -20 | 70 | °C | ||
| Relative Humidity | Non-condensing | 10 | 90 | % |
