Protocol

USB 2.0(WiFi + BT)

Interface

Pin Header

802.11 Standard

IEEE 802.11 a/b/g/n/ac + BT4.2

MIMO

2T2R

Antenna

2 x PCB Antenna for 2T2R
(2.4GHz & 5GHz dual band antenna)

Main Chip Vendor

Realtek

Main Chip Part No.

RTL8822BU

Frequency

2.412-2.484GHz

5.150-5.850GHz

Operating Voltage

DC 5V ± 10%

Maximum Output RF Power (Per chain)

2.4GHz @15dBm

5GHz @14dBm

Power Consumption(Max)

2W(Max)

Channel support

20/40/80MHz

Operating Temperature

-20℃ to 70℃
